The Cisco C-NIM-8T= is a high-density, Layer 2/Layer 3 configurable Gigabit Ethernet Network Interface Module (NIM) designed for the Cisco Catalyst 8000 Series Edge Platforms. It provides 8 ports of 10/100/1000 Mbps (RJ45) copper connectivity, seamlessly integrating LAN switching and WAN routing capabilities. As a direct upgrade for legacy ISR 4000 modules, it offers enhanced performance, security (MACsec), and flexibility for enterprise branch and SD-WAN environments.
8 x 1G RJ45 Ports: Supports 10BASE-T/100BASE-TX/1000BASE-T for full auto-sensing and backward compatibility.
Line-Rate Layer 2 Switching: Wire-speed switching on all 8 ports for efficient local traffic handling.
Dual Mode Ports: The last 2 highest-numbered ports can be natively configured as Layer 3 WAN/routed ports, matching the feature set of the router's built-in ports.
Jumbo Frames: Supports frame sizes up to 8 KB for optimized large-data transfers.
IEEE 802.1AE MACsec: Full line-rate encryption on all 8 ports.
Layer 2 Mode: Supports switch-to-switch MACsec for secure LAN extension.
Layer 3 Mode: Supports 256-bit WAN MACsec (Tag-in-Clear) for secure routed connections.
Integrated Security: Works with the router's firewall, VPN, and Zero Trust security framework.
Non-Blocking Architecture: Delivers full wire-speed performance across all ports.
VLAN Support: Up to 4095 VLAN IDs and 1024 active VLANs.
QoS: 8 egress queues per port, 802.1p class of service, and SD-WRR scheduling.
Auto-MDIX: Eliminates crossover cable requirements for simplified deployment.
Platform Support: Fully compatible with all Cisco Catalyst 8300 Series and Cisco Catalyst 8200/8200L Series edge platforms.
C8300-2N2S-6T, C8300-1N1S-6T, C8300-2N2S-4T2X, C8200-1N-4T, etc.
Software Support: Requires Cisco IOS XE 17.11.1a or later.
SD-WAN Ready: Fully manageable via Cisco vManage (version 20.11+).
| Parameter | Specification |
|---|---|
| Product SKU | C-NIM-8T= |
| Type | Gigabit Ethernet LAN/WAN NIM (Network Interface Module) |
| Ports | 8 × 10/100/1000BASE-T RJ-45 copper ports |
| Speed | 10 Mbps / 100 Mbps / 1 Gbps (auto-sensing) |
| Layer Support | Layer 2 switching (all ports); Layer 3 routing (last 2 ports) |
| MACsec | IEEE 802.1AE (256-bit) on all ports |
| PoE Support | No (PoE is available on the C-NIM-8M variant) |
| VLANs | 4095 VLAN IDs, 1024 active VLANs |
| Jumbo Frames | Up to 8192 bytes |
| Queuing | 8 queues per port, QoS/802.1p |
| Form Factor | Plug-in module (fits NIM slots on Catalyst 8000) |
| Weight | 8.1 oz (230 g) |
