MVI56E-LDM Linux Development Module for ControlLogix

The MVI56E-LDM is a powerful in-chassis edge module. It allows users to develop and deploy custom applications for ControlLogix® systems. Users are also able to create drivers for specialty Ethernet and Serial end-devices. The Linux Development module comes with a built-in API for backplane communications to the processor. The LDM library includes sample applications (with source code) for Sparkplug B MQTT, standard MQTT and Thingworx, which allows users to customize their IIoT (industrial Internet of Things) applications. With the separate development kit DVD, you as the developer control what this module can and cannot do!

Features and Benefits

Ideal for custom algorithm applications
Two independent Ethernet ports, and two independent, isolated, serial ports (RS232/422/485)
Scrolling LED display for custom messages (alarms, status, etc.)
Industrial fan-less design
Built-in API included for backplane communications to the processor
Linux Virtual Machine (VM) and development environment provided on our website
VM contains preinstalled toolchain and libraries
VM contains the popular Eclipse IDE
Multiple Ethernet and serial port example applications provided

Specifications

CPU	400MHz ARM9 G20
Operating System	Linux (kernel 2.6.33.7)
Linux Distribution	Timesys
System Memory	64MB SDRAM
Flash Memory	256MB NAND Flash
Compact Flash	16GB max supported (not provided)
