The Cisco IE-3300-8P2S-E is a high-performance, rugged, modular managed Layer 2/Layer 3 industrial Ethernet switch belonging to the Cisco Catalyst IE3300 Rugged Series. Powered by Cisco IOS XE with a Network Essentials license, it is equipped with 8 Gigabit Ethernet (10/1000/1000) PoE+ copper ports and 2 Gigabit Ethernet SFP fiber uplink ports. Engineered for extreme industrial environments, it delivers enterprise-grade networking, Power over Ethernet (PoE+) capability, and modular expansion to support Industrial IoT (IIoT) and Industry 4.0 deployments.
Hardened Industrial Design
Fanless, convection-cooled, IP30-rated metal enclosure
Extended operating temperature: -40°C to +75°C
High resistance to vibration (5g), shock (50g), surge, and electromagnetic interference
DIN-rail or wall-mountable compact form factor
Modular expansion slot for additional GE/2.5GE ports
Alarm I/O: 2 digital inputs, 1 relay output
Dual redundant 9.6–60V DC power inputs
Conformal coating option for corrosive atmospheres
PoE+ Connectivity
8 × 10/100/1000Base-T RJ45 ports supporting IEEE 802.3af/at PoE+
Total PoE power budget: 360W (supports full power to all 8 ports)
Ideal for powering IP cameras, access points, IP phones, and industrial sensors
2 × 1000Base-X SFP Gigabit Ethernet uplink ports
Advanced Network Resiliency
Sub-50ms recovery with REP, MRP, STP/RSTP/MSTP
IEEE 1588v2 Precision Time Protocol (PTP) (hardware-accelerated)
EtherChannel (LACP) for link aggregation
Hot-swappable modules and power
Enterprise Security (IOS XE)
Secure Boot, image signing, Trust Anchor module (TAm)
802.1X, MACsec 256, SSHv2, SNMPv3, ACLs, DHCP Snooping
IEC 62443-4-1/-2 industrial security compliance
Simplified Management & Automation
WebUI, CLI, SNMP, Cisco Catalyst Center, Industrial Network Director
USB 2.0 port + SD card slot (up to 32GB) for config backup
Dual console: 1 × RJ45 RS-232, 1 × Mini-USB Type B
Open APIs: RESTCONF, NETCONF, YANG
Flexible NetFlow (FNF) for traffic analytics
Industrial Protocols & Performance
Native support for EtherNet/IP (CIP), PROFINET, Modbus
QoS with 8 egress queues for critical traffic
IPv4/IPv6 static routing and RIP
Switching capacity: 56 Gbps; Forwarding rate: 41.6 Mpps
| Parameter | Details |
|---|---|
| Part Number | IE-3300-8P2S-E |
| Series | Cisco Catalyst IE3300 Rugged |
| Software | Cisco IOS XE, Network Essentials |
| Switch Type | Managed Layer 2/Layer 3, Modular |
| Copper Ports | 8 × 10/100/1000Base-T (PoE+) |
| Uplink Ports | 2 × 1000Base-X SFP (GE) |
| Expansion Slot | 1 × modular slot (GE/2.5GE) |
| PoE Budget | 360W (IEEE 802.3af/at) |
| Switching Capacity | 56 Gbps full-duplex |
| Forwarding Rate | 41.6 Mpps |
| MAC Table | 8,000 entries |
| Packet Buffer | 2.5 MB |
| Memory | 4 GB DRAM, 1.5 GB Flash |
| Removable Storage | SD card (up to 32GB), USB 2.0 |
| Power Input | Dual redundant 9.6–60V DC |
| Max Input Current | 10.6A @ 12V DC |
| Power Consumption | 35W (typical @ 12V) |
| Dimensions (H×W×D) | 152.4 × 91.4 × 134.6 mm |
| Weight | 1.7 kg |
| Operating Temp | -40°C to +75°C |
| Operating Humidity | 0–100% condensing |
