Cisco C9407R-96U-BNDL-A is a pre-configured, high-performance modular switch bundle from the Cisco Catalyst 9400 Series. It is designed for large-scale enterprise campus core, aggregation, and high-density access deployments. This all-in-one package combines a robust 7-slot chassis, high-density Gigabit Ethernet line cards, a powerful supervisor engine, and Cisco's DNA Advantage software license, providing a secure, automated, and highly scalable foundation for IoT, cloud, and next-generation enterprise networks.
High-Density Gigabit Connectivity & PoE
96 x 10/100/1000BASE-T RJ45 ports (2 x C9400-LC-48U line cards)
Universal Power over Ethernet (UPoE): Supports 60W per port (802.3bt) to power high-demand devices (PTZ cameras, 802.11ax APs, video endpoints)
Max PoE Budget: Up to 2880W per slot
Superior Performance & Scalability
Switching Capacity: 9 Tbps (with SUP-1XL)
Forwarding Rate: 1.08 Bpps
Unified Access Data Plane (UADP 2.0) for intelligent packet processing
480 Gbps per-slot bandwidth capacity
Carrier-Grade Resiliency
Dual redundant supervisor engines (SSO/NSF) for hitless failover
8 power supply bays for N+1 or N+N redundancy
Hot-swappable supervisors, line cards, power supplies, and fans
StackWise Virtual capable for simplified core clustering
Advanced Security & Software (DNA Advantage)
Cisco TrustSec & MACsec for end-to-end data plane security
Encrypted Traffic Analytics (ETA) to detect threats in encrypted flows
SD-Access architecture for policy-based automation and segmentation
Application Visibility and Control (AVC) for deep application insights
Open IOS XE with model-driven programmability (RESTCONF, NETCONF)
Operational Efficiency
Centralized management via Cisco DNA Center
Front-to-back/side-to-side airflow for optimized cooling
10RU rack-mountable form factor
| Component | Specification |
|---|---|
| Part Number | C9407R-96U-BNDL-A |
| Chassis | C9407R (7-slot, 10RU) |
| Supervisor Engine | C9400-SUP-1 |
| Line Cards | 2 x C9400-LC-48U (48-port 1G UPoE) |
| Total Ports | 96 x 1GBASE-T (PoE/UPoE) |
| Switching Capacity | 9 Tbps |
| Forwarding Throughput | 1.08 Bpps |
| MAC Address Table | 128K entries |
| Routing Table | 128K IPv4 / 64K IPv6 |
| VLANs | 4096 |
| Power Supply Bays | 8 (supports 2100W/3200W AC) |
| Dimensions (H x W x D) | 44.22 x 43.94 x 41.40 cm (17.41 x 17.30 x 16.30 in) |
| Weight | 28.58 kg (63.0 lb) (chassis with fan tray) |
| Software License | Cisco DNA Advantage |
